Simple, compact, and versatile, VT1 variable speed drives are the solution for innumerable industrial and service sector applications. Designed to control three-phase motors, they are ideal for controlling pumps, fans and air conditioning systems, packaging machines, belt conveyors, automatic doors, and many other applications.
Their extremely compact size makes them particularly suited to installation in electrical enclosures and machines with limited space availability.
Modbus-RTU industrial communications
The new VT1 series drives are equipped with 200 to 240VAC 50/60Hz single-phase power
The new VT1 series drives are equipped with 200 to 240VAC 50/60Hz single-phase power and a 0 to 240 VAC, 0 to 599Hz three-phase output, and feature a front-mounted RS485 port for remote control and monitoring by supervision systems or by a PLC or HMI controller.
They support the widely used Modbus-RTU industrial communications protocol and BACnet, typically used in building management and HVAC applications.
Wide range of load control applications
VT1 series variable speed drives offer a variety of motor control modes, making them outstandingly adaptable to a wide range of load control applications.
These include the V/F linear mode, used for common applications like belt conveyors and assembly machinery, quadratic control, generally used for controlling pumps and fans, and sensorless vector control, which offers optimal performance at low frequencies and for applications with highly dynamic speed variation.
For applications with special requirements, it is possible to define a custom multi-point curve or apply a boost to the initial torque output.
